Rigid Section

Layer(s) affected:                   HVAC

Alias:                                       None

Associated Commands:         [Duct Width] [Rigid Turn] [Flex Section]

[Flex Turn]

Used to insert straight duct sections. Set the Duct Width first. Can be inserted from a picked point to a picked point.

You may also pick the first point, move the mouse in the direction that the duct will be inserted, and enter a distance for the duct. Press Enter to finish.

The example below is a 24” duct, 20 feet long.
