Line w/Size

Layer(s) affected:                   SPRKDAT2, SPRKDATA

Alias:                                       None

Associated Commands:         [Tee] [Line] [Existing Line] [Auto Line] [90 Ell] [45 Ell] [Double Ell] [Pretty Pipes]

Used to draw line piping by the same methods as with the Line command. This command will also insert pipe sizes and lengths. The diameter will be inserted according to the setting in the Size Pipe Setup command. If no size is selected from Size Pipe Setup, HydraCAD will insert a question mark as the pipe diameter.

HydraCARDs (Troubleshooting)

For HydraCARDs regarding Line w/ Size: [Click Here]
